OTDR
Réamhrá Bene:
ST3200F series OTDR adopts 4.3 inch capacities touch screen. It integrates 12 functions, such as auto OTDR, expert OTDR, event map, optical power meter, RJ45 cable tracker, and "computer level" file management to meet various test requirements in different occasions.
Sonraíocht:
OTDR | |||||||
Mionsamhail | ST3200F-A | ST3200F-B | ST3200F-C | ST3200F-D | ST3200F-E | ||
Cineál | G.652 SM | ||||||
Tonnfhad | 1310/1550±20nm | 1310/1550±20nm | 1625nm | 1650nm | 850/1300nm(SM) | ||
Raon Dinimiciúla | 26dB/24dB | 32/30dB | 22dB | 22dB | 22/24dB | ||
Oíche ShamhnantBlindZone | 2.5m | ||||||
ATT BlindZone | 8m | ||||||
Raon Tástála | 500m/1km/2km/4km/8km/16km/32km/64km/100km | ||||||
Leithead Pulse | 3ns/5ns/10ns/20ns/30ns/50ns/80ns/160ns/320ns/500ns/800ns/1us/2us/3us/5us/8us/10us/20us | ||||||
Cruinneas | ± (1m plus Sample interval plus 0.005 percent Test distance) | ||||||
Líneacht | Níos lú ná nó cothrom le0.05dB/dB | ||||||
Pointí Samplacha | 16k128k | ||||||
SamRún | 0.05m8m | ||||||
LossResolution | 0.001dB | ||||||
Tairseach Caillteanais | 0.20dB | ||||||
Réiteach Raon | 0.001m | ||||||
Innéacs Refractive | 1.00000-2.00000 | ||||||
Machnamh Acc | ±3dB | ||||||
Formáid Chomhaid | Formáid Chaighdeánach Comhaid SOR | ||||||
Anailís Caillteanas | Modh 4 phointe / modh 5 phointe | ||||||
Laser Safety | Aicme II | ||||||
Cónascaire | FC/UPC (SC Idirmhalartaithe,ST) Nó SC/APC | ||||||
Ráta Athnuachan | 3Hz (Cineál.) | ||||||
Iltascáil | Tacaíocht | ||||||
OPM | LS | Fad Cábla RJ45 | |||||
Raon Tonn | 800nm1700nm | Tonnfhad | mar an gcéannaOTDR | Fad Tástála | Greater than or equal to 300m | ||
Test Range: -70 plus 10dBm/ -50 móide 26dBm | Cineál Léasair | FP - LD | Daoine eile | ||||
Cumhacht | Níos mó ná nó cothrom le -5dBm | Taispeáint:4.3 inches 800480 IPS TFT - LCD touch screen | |||||
Rún | 0.01dB | Stabilitycw,±0.5dB/15min (Tar éis 15 nóiméad de réamhthéamh) | |||||
Éiginnteacht | ±5 percent | FC/UPC (SC,ST available) | Soláthar leictreachas: AC/DC adapter Ionchur:100V240V, 50/60Hz, 0.6A Aschur: 5v 2A Lithium battery:3.7V,4000mAh | ||||
Aitheantas minicíochta | CW/270/330/1k/2kH | CW/270Hz/330Hz/1kHz/2k | |||||
Cónascaire | Uilíoch FC/SC/ST | TonnRéiceach | Tacaíocht | Oibriú Cadhnra | Continuous test> 12h | ||
Tonn Aitheantas | Tacaíocht | Tástáil Caillteanas Optúil | Stóráil Sonraí | 8GB,Níos mó ná nó cothrom le20 míle cuair | |||
VFL | Tonnfhad | céanna with LS | Comhéadan Sonraí | USB Type C | |||
Tonnfhad | 650nm±20nm | Tástáil IL | Tacaíocht | Teocht Oibre | -10 céim móide 50 céim | ||
Cumhacht Aschuir | Níos mó ná nó cothrom le 10mW | RJ45 cable tracker | Teocht Stórála | -40 céim móide 70 céim | |||
Mód | CW/1Hz/2Hz | Mód | Rianú digiteach | Taise Choibhneasta | 0〜95 faoin gcéad Neamh-chomhdhlúthú | ||
Ceanglóir FC/UPC | Fad | Níos mó ná nó cothrom le 300m | Meáchan | Níos lú ná nó cothrom le 0.5kg | |||
Leibhéal Sábháilteachta | Aicme III | Support Online/Line PairTracker | Méid | 173mm 109mm 45mm | |||
SENTER has established good cooperation with many OTDR suppliers agus tionscadail in European and Asian, and the sales volume of mini OTDR is up to 600 units per month, which has laid a good foundation for SENTER's development in optical fiber testing market.
We believe that with the continuous development of telecom industry, SENTER will have closer cooperation with achieve better development.
Q2: What's your MOQ?
A: Tá an MOQ bunaithe ar shraith táirgí éagsúla difriúil i ndáiríre (1-10pcs), seol d'fhiosrúchán chuig na díolacháin le haghaidh aiseolais chruinn
C3: An féidir leat samplaí saor in aisce a thairiscint?
A: Yes the free samples are available for the product verify, don't hesitate to ask for it!
C4: Cad mar gheall ar an am luaidhe?
A: 1 seachtaine don ordú rialta qty Níos lú ná nó cothrom le 100 ríomhaire. Is féidir an stoc a ullmhú roimh ré bunaithe ar-chomhpháirtíocht fadtéarmach!
